Open System Preferences - Network from Mac applications menu. Click the “+” button to create a new service, then select VPN as the interface type, and choose L2TP over IPsec from the pull-down menu. Server Address: Enter the public IP address (found in the Dashboard, under Security appliance - Monitor - Appliance status - Uplink). This was built with Meraki VPN connections in mind but further development may allow other tunneltypes and authentication modes. This module has been tested on Windows 10, Powershell 5.1-7.0 It utilizes 'VPNCredentialsHelper' by Paul Stancer and will install the module/ import it, upon using the creation function.

Note:

Apple has removed the native support and pass-through capabilities of PPTP VPN connections through IOS10+ devices. The Meraki Client VPN utilizes a more secure L2TP connection an can still successfully connect through a mobile hotspot broadcast from an iOs device.

1. Navigate to Settings -> General -> VPN -> Add VPN Configuration…
2. On the Add Configuration screen that appears, set the Type to L2TP.
3. Enter a Description for the VPN connection.
4. Enter the public IP of the MX device (found in Dashboard, under Security appliance -> Monitor -> Appliance status -> Uplink) as the Server.
5. Under Account, enter the username to be used to connect to the Client VPN.
6. Enter the Password if desired. If the password is left blank, it will need to be entered each time the device attempts to connect to the Client VPN.
7. Enter the VPN Secret.
8. Ensure that Send All Traffic is set to On.
9. Save the configuration.

Meraki Vpn Ios Free

Related Articles

1. The Meraki L2TP client VPN set up had no problem connecting with iPhone / iPad client. Since Cisco AMP for Endpoints (Clarity) is enabled via Meraki MDM it is not possible to establish a connection. The iOS device displays the error 'The L2TP-VPN server did not respond.
2. Meraki MDM also fails to load VPN parameters as it requires a Windows profile (appart from the Meraki Agent). Apparently, you cannot have two MDM profiles on Windows 10. There's also the issue of authentication. Meraki does not support Azure Active Directory.
3. Jul 01, 2019 Meraki Client VPN (L2TP+PSK) @Martin Norfolk I haven't gotten any traction with this other than finding CMAK (Connection Manager Administrator Kit), the feature/role you can install on Windows Server to create a connection and then distribute to your end users.

Meraki Client Vpn Ios

Note:

Currently only the following authentication mechanisms are supported:

• User authentication: Active Directory, RADIUS, or Meraki hosted authentication.
• Machine authentication: Preshared keys (shared secret)

When using Meraki hosted authentication, VPN account/user name setting on client devices (PC/Mac) is the user email address entered in the Dashboard.

1. Open System Preferences -> Network from Mac applications menu. Click the “+” button to create a new service, then select VPN as the interface type, and choose L2TP over IPsec from the pull-down menu.

• Server Address: Enter the public IP address (found in the Dashboard, under Security appliance -> Monitor -> Appliance status -> Uplink)
• Account Name: Enter the account name of the user (based on active directory, RADIUS, or Meraki Hosted authentication)

Meraki Vpn Ios Apk

2. Click Authentication Settings and provide the following information:

• User Authentication -> Password: User password (based on Active Directory, RADIUS, or Meraki Hosted authentication)
• Machine Authentication -> Shared Secret: The preshared key that you’ve created in Configure -> Client VPN settings for the MX.

3. Click OK to go back to the main VPN settings page, then click Advanced and enable the Send all traffic over VPN connection option.

Caution:

The VPN connectivity will not be established if you do not enable the Send all traffic over VPN connection option.
